Single System 60 Inch Computerized Sweater Knitting Machine

    Buy cheap Single System 60 Inch Computerized Sweater Knitting Machine from wholesalers

    Buy cheap Single System 60 Inch Computerized Sweater Knitting Machine from wholesalers
    • Buy cheap Single System 60 Inch Computerized Sweater Knitting Machine from wholesalers

    Single System 60 Inch Computerized Sweater Knitting Machine

    Ask Lasest Price
    Brand Name : YIMA
    Model Number : GSJX-1-60
    Certification : CE ISO
    Price : negotiable
    Payment Terms : T/T, L/C, Western Union, MoneyGram, D/P, D/A
    Supply Ability : 1500 Set/Sets per month
    Delivery Time : 10-15 working days
    • Product Details
    • Company Profile

    Single System 60 Inch Computerized Sweater Knitting Machine


    High Speed Sweater Computerized Flat Knitting Machine Single System


    PRODUCT FEATURES


    ModelGSJX-1-60
    Gauge5G,6G,7G,8G,9G,10G,12G,13G,14G,15G
    Knitting SystemSingle System Single Carriage
    Knitting Width60 Inch
    Knitting SpeedMax.1.2m/Sec
    Knitting FunctionTranfer,Tuck,Miss,Jacquard,Intarsia,Hide Or Apparent Shaping.
    Stitch DensityStitch System Controlled By Stepping Motor,32 Section Stitch Selectable,Adjustable Scope Supported By Subdivision Technology:0-650
    RackingControlled By Ac Servo Motor,Racking Within 2 Inches And With Fine Adjustiing Function.
    Drive SystemSynchronous Belt Drive,Ac Servo System
    Needle SelectionControlled By Computer,Electric Magnet Needle Choose System With High Efficiency.
    Scissor And ClampIncluding 2 Scissor And 4 Clamps ,Which Individually Controlled By 6 Motors Separately,Located The Both Of Needle Bed Separately,Further To Increase The Work Efficiency And To Reduce Yarn Consumption.
    Yarn Carrier1x6yarn Carriers On Each Side Of 3 Guide Rails,Shiftable On Any Needle Position
    Take Down RollerProgrammed Instruction Controlled By Stepping Motor,32 Section Levels Selection Adjustable Area:0-100
    Sinker SystemAssist Knitting,Have Various Results Of Shaping And Stop.
    Protection SystemThe Machine Will Automatically Alarm If Yarn Breaking,Float Yarn,Rewind,End Of Knitting,Fail Of Racking,Needle Breakage And Error Programming Occur Ect.
    Control System1,Adopt Lcd Screen,Input Device:Usb,System Memory 256mb,A Great Amount Of Design Files Can Be Stored.2,Monitoring Menu,Each Kind Of Operating Parameter,Can Be Shown,And They Can Be Adjusted At Any Time When The Machine Is Running.3,Design System Is Visual And Easy To Understand And Upgrad.4,Multi Language Version,There Are Chinese,English Etc.
    Power220v ,Single-Phase,Have Memorizing Function At The Power-Off Moment



    PRODUCT DETAILS


    SINKER SYSTEM
    Flat knitting machine for knitting needle movement in the rise and fall with the regularity of the moment,to achieve the stitch transfer,stitch press off,stitch knit,stitch tuck such as knitting effects,need to help latch needle from sinker to complete,improve the capacity of weaving.Sinker control system make the function of sinker adjustable to achieve.

    YARN FEEDER
    Yarn feeders can be adjusted according to the knitting width of fabric,also can be adjusted by programmable fine tune according to the carriage’s running speed.

    POWER FAILURER PROTECTION
    With power failure protection,the machine is able to automatically memorize the data upon power failure the and recover the data when the power is restored,so that the machine can continue the pending work according the programmed patterns,which avoids the waste of yarn ans saves the time,without compromising the quality of the fabrics.

    EMERGENCY SWITCH
    Upon emergency or when doing maintenance such as yarn going through,needle changing and residue cleaning,this switch allows the machine to stop working under a locked status,no need to disconnect the main power.In this way,the data of the machine is properly kept and accidents can be avoided,which ensure the safety of both operator and machine.

    CONTINUOUS KNITTING
    The machine has the function of continuous knitting. Different patterns can be woven circularly. When several different pattern files need to be woven, only all the pattern files to be executed need to be stored in a unified way. After the selected pattern is woven, the machine will automatically select its remaining patterns for weaving, which not only saves time and yarn use, but also facilitates the production management of customers.

    Newest Type Baby Vest Computerized Knitting Machine Factory Sale

    APPLICATION FIELDS

    Single System 60 Inch Computerized Sweater Knitting Machine

    ABOUT US

    Guosheng is the professional manufacturer of flat knitting machine since 1992.Until now,it has exported to more than 35 countries.
    We pursue quantity and quality,as it’s our responsibility to give you a satisfactory purchasing experience.
    Guosheng has a complete inventory system, which can meet the needs of every customer, and sets the delivery period at about 10-15 days.Even if you require customization, our assembly line can effectively improve work efficiency and greatly shorten the delivery time.
