Glove Computerized Flat Knitting Machine Fully Jacquard Multi Gauge
PRODUCT DESCRIPTION
Flat knitting machine can knit basic stitch like plain stitch, rib
fabric, links and links, interlock stitch, etc. irregular multi
color jacquard, twit flowers weft organization, cord weave, racked
stitch, cable, etc.
Flat knitting machine is suitable to use synthetic, wool, acrylic,
mixed fiber, yarn material etc to knit sweater,collar,shoe
upper,school uniform.ready-made cardigan, hat,scarf and accessories
of cloth.
PRODUCT FEATURES
| Model | GSJX-3-60 |
| Gauge | 3G,3.5G,3-5-7G,5G,6G,7G,8G,9G,10G,12G,13G,14G,15G |
| Knitting System | Three System Single Carriage |
| Knitting Width | 60 Inch |
| Knitting Speed | Max.1.2m/Sec |
| Knitting Function | Tranfer,Tuck,Miss,Jacquard,Intarsia,Hide Or Apparent Shaping. |
| Stitch Density | Stitch System Controlled By Stepping Motor,32 Section Stitch
Selectable,Adjustable Scope Supported By Subdivision
Technology:0-650 |
| Racking | Controlled By Ac Servo Motor,Racking Within 2 Inches And With Fine
Adjustiing Function. |
| Drive System | Synchronous Belt Drive,Ac Servo System |
| Needle Selection | Controlled By Computer,Electric Magnet Needle Choose System With
High Efficiency. |
| Scissor And Clamp | Including 2 Scissor And 4 Clamps ,Which Individually Controlled By
6 Motors Separately,Located The Both Of Needle Bed
Separately,Further To Increase The Work Efficiency And To Reduce
Yarn Consumption. |
| Yarn Carrier | 2x8yarn Carriers On Each Side Of 4 Guide Rails,Shiftable On Any
Needle Position |
| Take Down Roller | Programmed Instruction Controlled By Stepping Motor,32 Section
Levels Selection Adjustable Area:0-100 |
| Sinker System | Assist Knitting,Have Various Results Of Shaping And Stop. |
| Protection System | The Machine Will Automatically Alarm If Yarn Breaking,Float
Yarn,Rewind,End Of Knitting,Fail Of Racking,Needle Breakage And
Error Programming Occur Ect. |
| Control System | 1,Adopt Lcd Screen,Input Device:Usb,System Memory 256mb,A Great
Amount Of Design Files Can Be Stored.2,Monitoring Menu,Each Kind Of
Operating Parameter,Can Be Shown,And They Can Be Adjusted At Any
Time When The Machine Is Running.3,Design System Is Visual And Easy
To Understand And Upgrad.4,Multi Language Version,There Are
Chinese,English Etc. |
| Power | 220v ,Single-Phase,Have Memorizing Function At The Power-Off Moment |
PRODUCT DETAILS
PROBE ALARMING DEVICE
Probe alarming device is a breakthrough as compared with the
current monotonous detecting mode where the probes sway from side
to side.This device is able to completely,safely and effectively
realize the detection and avoid the damaged to the fabrics and
other failures.So as to ensure the normalized operation of the
machine and increase the working efficiency of knitting process.
YARN TRANSPORTATION DEVICE
The yarn transportation device is installed between the yarn bucket
and knitting system,which greatly improves the uneven tension
caused by overlong yarn journey,When then yarn is sued up or
breakage of yarn takes place due to any reason,the sensor in the
yarn transportation device will alarm and the machine stops
working.This prevents the broken yarn from entering then knitting
area,making the connection of yarn easily and avoiding the damages
to the quality of fabrics.
LCD DISPLAYER
Machine adopts industry LCD display with touch control,all time
monitoring function.The data of knitting
amount,time,speed,roller,density,yarn carrier etc,is clearly shown
and can be adjusted in the process.It is most convenient and
efficient way to amend the data.
SINKER SYSTEM
Flat knitting machine for knitting needle movement in the rise and
fall with the regularity of the moment,to achieve the stitch
transfer,stitch press off,stitch knit,stitch tuck such as knitting
effects,need to help latch needle from sinker to complete,improve
the capacity of weaving.Sinker control system make the function of
sinker adjustable to achieve.
YARN FEEDER
Yarn feeders can be adjusted according to the knitting width of
fabric,also can be adjusted by programmable fine tune according to
the carriage’s running speed.
POWER FAILURER PROTECTION
With power failure protection,the machine is able to automatically
memorize the data upon power failure the and recover the data when
the power is restored,so that the machine can continue the pending
work according the programmed patterns,which avoids the waste of
yarn ans saves the time,without compromising the quality of the
fabrics.
EMERGENCY SWITCH
Upon emergency or when doing maintenance such as yarn going
through,needle changing and residue cleaning,this switch allows the
machine to stop working under a locked status,no need to disconnect
the main power.In this way,the data of the machine is properly kept
and accidents can be avoided,which ensure the safety of both
operator and machine.
APPLICATION FIELDS
STRONG AFTER-SALE SERVICE TEAM
You will get free machine operation training & pattern-designing
training as soon as you buy our machine.
Mature and attentive service is what Guosheng hold as the principle
of service,machine operation training for free and
pattern-designing training for free to free customers from all the
worries.
