Single Phase Wool Textile 7G Hat Knitting Machine

    Buy cheap Single Phase Wool Textile 7G Hat Knitting Machine from wholesalers

    Buy cheap Single Phase Wool Textile 7G Hat Knitting Machine from wholesalers
    • Buy cheap Single Phase Wool Textile 7G Hat Knitting Machine from wholesalers

    Single Phase Wool Textile 7G Hat Knitting Machine

    Ask Lasest Price
    Brand Name : GANGJI
    Model Number : GSJX-3-52
    Certification : CE ISO
    Price : negotiable
    Payment Terms : T/T, L/C, Western Union, MoneyGram, D/A, D/P
    Supply Ability : 50 sets per day
    Delivery Time : 10-15 working days
    • Product Details
    • Company Profile

    Single Phase Wool Textile 7G Hat Knitting Machine

    Winter Wool Hat & Scarf Flat Knitting Machine Textile Machinery


    • Machine parameter

    GAUGE3G,3.5G,3-5-7G,5G,6G,7G,8G,9G,10G,12G,13G,14G,15G,16G
    SYSTEMTHREE SYSTEM SINGLE CARRIAGE
    KNITTING WIDTH52 INCH
    KNITTING SPEEDMAX.1.2M/SEC
    KNITTING FUNCTIONTRANFER,TUCK,MISS,JACQUARD,INTARSIA,HIDE OR APPARENT SHAPING.
    STITCH DENSITYSTITCH SYSTEM CONTROLLED BY STEPPING MOTOR,32 SECTION STITCH SELECTABLE,ADJUSTABLE SCOPE SUPPORTED BY SUBDIVISION TECHNOLOGY:0-650
    RACKINGCONTROLLED BY AC SERVO MOTOR,RACKING WITHIN 2 INCHES AND WITH FINE ADJUSTIING FUNCTION.
    DRIVE SYSTEMSYNCHRONOUS BELT DRIVE,AC SERVO SYSTEM
    NEEDLE SELECTIONCONTROLLED BY COMPUTER,ELECTRIC MAGNET NEEDLE CHOOSE SYSTEM WITH HIGH EFFICIENCY.
    YARN CARRIER2x8YARN CARRIERS ON EACH SIDE OF 4 GUIDE RAILS,SHIFTABLE ON ANY NEEDLE POSITION
    TAKE DOWN ROLLERPROGRAMMED INSTRUCTION CONTROLLED BY STEPPING MOTOR,32 SECTION LEVELS SELECTION ADJUSTABLE AREA:0-100
    SINKER SYSTEMASSIST KNITTING,HAVE VARIOUS RESULTS OF SHAPING AND STOP.
    PROTECTION SYSTEMTHE MACHINE WILL AUTOMATICALLY ALARM IF YARN BREAKING,FLOAT YARN,REWIND,END OF KNITTING,FAIL OF RACKING,NEEDLE BREAKAGE AND ERROR PROGRAMMING OCCUR ECT.
    CONTROL SYSTEM1,ADOPT LCD SCREEN,INPUT DEVICE:USB,SYSTEM MEMORY 256MB,A GREAT AMOUNT OF DESIGN FILES CAN BE STORED.2,MONITORING MENU,EACH KIND OF OPERATING PARAMETER,CAN BE SHOWN,AND THEY CAN BE ADJUSTED AT ANY TIME WHEN THE MACHINE IS RUNNING.3,DESIGN SYSTEM IS VISUAL AND EASY TO UNDERSTAND AND UPGRAD.4,MULTI LANGUAGE VERSION,THERE ARE CHINESE,ENGLISH ETC.
    POWER220V ,SINGLE-PHASE,HAVE MEMORIZING FUNCTION AT THE POWER-OFF MOMENT

    PRODUCT DETAILS


    YARN FEEDER
    Yarn feeders can be adjusted according to the knitting width of fabric,also can be adjusted by programmable fine tune according to the carriage’s running speed.

    PROBE ALARMING DEVICE
    Probe alarming device is a breakthrough as compared with the current monotonous detecting mode where the probes sway from side to side.This device is able to completely,safely and effectively realize the detection and avoid the damaged to the fabrics and other failures.So as to ensure the normalized operation of the machine and increase the working efficiency of knitting process.

    YARN TRANSPORTATION DEVICE
    The yarn transportation device is installed between the yarn bucket and knitting system,which greatly improves the uneven tension caused by overlong yarn journey,When then yarn is sued up or breakage of yarn takes place due to any reason,the sensor in the yarn transportation device will alarm and the machine stops working.This prevents the broken yarn from entering then knitting area,making the connection of yarn easily and avoiding the damages to the quality of fabrics.

    POWER FAILURER PROTECTION
    With power failure protection,the machine is able to automatically memorize the data upon power failure the and recover the data when the power is restored,so that the machine can continue the pending work according the programmed patterns,which avoids the waste of yarn ans saves the time,without compromising the quality of the fabrics.


    Single Phase Wool Textile 7G Hat Knitting Machine

    • Computerized Flat Knitting Machine Details

    Single Phase Wool Textile 7G Hat Knitting Machine

    Single Phase Wool Textile 7G Hat Knitting Machine

    • Sound Quality Control System

    Single Phase Wool Textile 7G Hat Knitting Machine

    Single Phase Wool Textile 7G Hat Knitting Machine

    • We Take Every Product Like A Child

    Single Phase Wool Textile 7G Hat Knitting Machine

    • The Auxiliary Of Flat Knitting Machine

    Single Phase Wool Textile 7G Hat Knitting Machine

    • Guosheng Knitting Machine Around The World

    Single Phase Wool Textile 7G Hat Knitting Machine

    • We Attend The Exhibition Every Year

    Single Phase Wool Textile 7G Hat Knitting Machine

    • Welcome To Guosheng Machinery Factory

    Single Phase Wool Textile 7G Hat Knitting Machine

    • Contact Us Without Hesitation

    Single Phase Wool Textile 7G Hat Knitting Machine
